Full Band E-12-100W High Power 5G Omnidirectional Mobile Phone Signal Jammer

$8,500.00
  • Effectively blocks frequency bands such as GSM/CDMA/DCS/WCDMA/LTE/WiFi (tri-band)/5G;
  • 1-100M jamming distance;
  • Built-in aluminum alloy radiator for long-term stable operation;
  •  Utilizes advanced foreign chips and technology, soft-start circuit design, high integration;
  • Utilizes advanced foreign chips and technology, soft-start circuit design, high integration;
  • Employs ultra-high frequency interference technology;
Send Inquiry Now>

N-14-120W Built-in Directional Power Adjustable High Power 5G Mobile Phone Signal Disruptor with 100m ShieldN-14-120W Built-in Directional Power Adjustable High Power 5G Mobile Phone Signal Disruptor with 100m Shield
N-14-120W Built-in Directional Power Adjustable High Power 5G Mobile Phone Signal Disruptor with 100m Shield

100W: 8500

100W: 8500
8500
Overview

E-12-100W 5G Mobile Phone Signal Jammer is the nemesis of wireless cheating devices such as mobile phones, WIFI, Bluetooth, and electronic watches. It serves as a security guard and purification expert in confidential meetings and standardized examination venues.

The jammer is an omnidirectional full-band communication signal jammer, all of which are seventh-generation green signal jammers. They only block the reception of on-site mobile phone devices and do not affect surrounding base stations at all.



Specification

Category Performance and Metrics
Size 430 × 335 × 125 mm (Length × Width × Height)
Weight 7.9 kg (main unit)
Shielding Range 1–100 m (depending on the strength of the base station signal)
Power Supply & Consumption AC110–220V / DC24V / 15A, Power Consumption: 360W
Operating Temperature -10°C to +55°C
Storage Temperature -20°C to +60°C

Electrical Parameters

Output Terminal Operating Frequency Frequency Range Output Power Channel Output Power
5G 758–803 MHz 40 dBm 5 dBm / 30 kHz (min)
CDMA 851–894 MHz 40 dBm 5 dBm / 30 kHz (min)
GSM 925–960 MHz 40 dBm 5 dBm / 30 kHz (min)
DCS 1805–1990 MHz 40 dBm 2 dBm / 30 kHz (min)
3G 2010–2170 MHz 40 dBm 2 dBm / 30 kHz (min)
3G1 2110–2170 MHz 40 dBm 2 dBm / 30 kHz (min)
4G1 2300–2400 MHz 40 dBm 2 dBm / 30 kHz (min)
4G2 2500–2690 MHz 40 dBm 2 dBm / 30 kHz (min)
WiFi 2.4G 2400–2500 MHz 36 dBm 2 dBm / 30 kHz (min)
WiFi 5.2G 5150–5300 MHz 36 dBm 2 dBm / 30 kHz (min)
WiFi 5.8G 5725–5850 MHz 36 dBm 2 dBm / 30 kHz (min)
5G1 3300–3800 MHz 40 dBm 2 dBm / 30 kHz (min)
5G2 4800–4960 MHz 40 dBm 2 dBm / 30 kHz (min)
