120W Prison Customizable Full-band K-16 Omnidirectional Cell Phone Blocker

$480.00

Omnidirectional Defense Against Prison Smuggling

  • Full-Band Blocking: Blocks 2G–5G, Wi-Fi & Bluetooth to stop contraband phone use and criminal plans.
  • Omnidirectional Defense: 360° coverage eliminates dead zones, protecting every corner of prisons.
  • Customizable Blocking Range: Provides flexible protection for any prison size or layout.
  • Flexible Installation: Wall, ceiling, or desktop for any high-security area.
  • Reliable 24/7 Operation: Advanced radiator and silent fans ensure uninterrupted protection during long-duration surveillance.
  • Factory-Direct Reliability: 21 years of R&D, certified quality, and global technical support.
Send Inquiry Now>

: 120W Prison Customizable Full-band K-16 Omnidirectional Cell Phone Blocker

cellphone detector with multiple frequency on a white backgroundA portable signal detector with multiple fans inside a metal case, with visual indicators for 5G, 2G, 3G, 4G, and WiFi frequencies.
120W Prison Customizable 2/3/4/5G/WIFI Bluetooth Blocker Adjustable N-14 Directional Cell Phone Signal Blocker
50W Full-band K-12 Omnidirectional Cell Phone Blocker 5G WIFI Blocker for Anti-cheating - DescBoostTable comparing different models of communication devices for various use scenarios with specifications and reasons.
50W Exam Full-band K-12 Omnidirectional Cell Phone Blocker 5G WIFI Bluetooth Blocker
80W Full-band K-14 Omnidirectional Cell Phone Blocker for Wall-mounted＆Desktop - DescBoost80W Full-band K-14 Omnidirectional Cell Phone Blocker for Wall-mounted＆Desktop - DescBoost
80W Meeting Rooms Customizable Full-band K-14 Omnidirectional Cell Phone Bluetooth Blocker
A white classroom cell phone jammer with symbols indicating 5G, GSM, 2G, 3G, 4G, and WiFi frequencies. show the detailed image of phone jammer
120W Prison Customizable Full-band K-16 Omnidirectional Cell Phone Blocker
A black portable cell phone jammer device with indicators for 5G, GSM, 2G, 3G, 4G, and WIFI.Black portable phone jammer with handle and fans on a white background
100W E-12 Directional Full-band Cell Phone Jammer 5G GSM WIFI Bluetooth Signal Jammer
Overview

Successful Cases
Our Company


No Phones. No Smuggling. No Escape. No Risk.

By deploying cell phone blockers, correctional facilities can instantly cut off calls, texts, and data connections—eliminating contraband phones, unauthorized communication, and smuggling attempts, while ensuring a controlled, confidential, and secure environment.

Features

Support all cellular bands

The blocker can support all the 2G/3G/4G/5G cellular bands of different mobile network operators and Wi-Fi frequency bands all in one device.

Plug and play

The blocker may be used in various scenarios and places, where the cellular frequencies may be different. To make the service fulfillment easy, the blocker is designed to adapt to different radio environment automatically. It supports plug and play, without the necessity of parameter setting.

No interference to base stations

It only blocks the reception of on-site mobile devices and does not affect surrounding base stations.

7-50M Omnidirectional Blocking

The K-14-5G device uses an omnidirectional antenna array, significantly increasing the blocking distance. It blocks various types of mobile phone signals within a range of 7-50 meters, completely interrupting all communications.

Remote and local management

The signal blocker could be centrally managed through the internet and standard TCP/IP protocol or configured locally with a PC.

cell phone blocker

Precautions:

1. Factors affecting the actual shielding range include signal field strength, base station distance, mobile phone format, obstacles, installation height, installation specifications, etc.
2. It is normal for the host to heat up after working for a long time. If the temperature is too high, please turn off the power and contact your local dealer
3. The normal installation height is 1.8m～2.5m, try to choose the place where there is no obstacle between the target shielding area. The wall-mounted installation requires the antenna to be vertically upward. When using on a desktop, the antenna can be folded 90 degrees and then vertically upward. There should be no AC power lines or other audio and video lines within 0.2 meters of the antenna.
4. In order to avoid possible interference with some electronic equipment, please try to keep 1~2 meters above the following common equipment: audio, wireless microphone, radio, computer, TV, Wi-Fi router, Rcied, etc.
anti drone company
Specification

Parameters Performance and Metrics
Size 465 × 433 × 89 mm (Length × Width × Height)
Weight 4.5 kg
Shielding Range 10–50 meters (depending on the strength of the base station signal)
Power Supply & Consumption AC 110–220V / DC 24V / 25A, Power Consumption: 500W
Operating Temperature -10℃ to +55℃
Storage Temperature -20℃ to +60℃

Electrical Parameters

Output Terminal Operating Frequency Frequency Range Output Power Channel Output Power
5G 758–803 MHz 40 dBm (10W) 5 dBm / 30 kHz (min)
CDMA 870–880 MHz 40 dBm (10W) 5 dBm / 30 kHz (min)
GSM 930–960 MHz 40 dBm (10W) 5 dBm / 30 kHz (min)
DCS 1805–1880 MHz 39.5 dBm (9W) 2 dBm / 30 kHz (min)
PHS 1880–1990 MHz 39.5 dBm (9W) 2 dBm / 30 kHz (min)
3G 2010–2145 MHz 39 dBm (8W) 2 dBm / 30 kHz (min)
3G1 2110–2170 MHz 39 dBm (8W) 2 dBm / 30 kHz (min)
4G1 2300–2390 MHz 39 dBm (8W) 2 dBm / 30 kHz (min)
4G2 2500–2600 MHz 39 dBm (8W) 2 dBm / 30 kHz (min)
5G 2600–2690 MHz 39 dBm (8W) 2 dBm / 30 kHz (min)
WiFi 2.4G 2400–2500 MHz 37 dBm (5W) 2 dBm / 30 kHz (min)
WiFi 5.2G 5150–5300 MHz 37 dBm (5W) 2 dBm / 30 kHz (min)
WiFi 5.8G 5725–5850 MHz 37 dBm (5W) 2 dBm / 30 kHz (min)
5G1 3300–3500 MHz 38.5 dBm (7W) 2 dBm / 30 kHz (min)
5G2 3500–3800 MHz 38.5 dBm (7W) 2 dBm / 30 kHz (min)
5G3 4800–4960 MHz 37 dBm (5W) 2 dBm / 30 kHz (min)
VHF (optional) 136–174 MHz 37 dBm (5W) 2 dBm / 30 kHz (min)
UHF (optional) 400–470 MHz 37 dBm (5W) 2 dBm / 30 kHz (min)
